Cable Sizing

7.0 CPD Hours

Standard Rate
£395.00  +VAT
Member Rate
£315.00  +VAT
  • Electrical Services

Online Learning

This course employs a cable sizing template that acts as a visual checklist for the necessary design decisions and calculations to meet the requirements of BS 7671:2018. The Cable Sizing Template can be used as a stand-alone design sheet, or it can be used to inform the process, enabling a more cost effective use of commercial cable-sizing software with greater understanding of the design methodologies that they are typically based around.

Make your way through this course at your own pace with the following:

  • Cable Sizing Topics
  • Additional Resources
  • Four Activity Pages
  • CPD Certificate on completion

All On Demand modules and courses have a one year access period. Any training purchased will expire one year after the purchase date.

This course covers:

  • Welcome
  • Introduction
  • Cable Sizing Overview
  • Protection Against Overload
  • Protection Against Short-Circuit
  • Fault Protections
  • Voltage Drop
  • Network Analysis
  • Busbar and Busbar Trunking
  • Case Studies
  • Conclusion

CIBSE online learning courses are suitable for those wishing to enhance and support their current knowledge base, as well as graduates within an engineering discipline.
Each unit has been peer reviewed and tested through this group. The units allow students to take a coordinated journey through an individual topic or a series of topics. The units form the backbone of several corporate training schemes.

  • To provide a best-practice, ‘structured’ approach to cable sizing
  • To enable you to demonstrate compliance with ISO9001 and other quality assurance measures
  • To enable you to provide an audit trail of the design/decision process
  • To provide you with a understanding to assess the impact
  • (If any) on conductor sizes for last-minute and/or on-site design changes
  • To enable you to ‘spot-check’ computer designed solutions

Once completed, this module will allow users to design cables to meet the requirements of BS 7671:2018 (Requirements for electrical installations, IET Wiring Regulations, Eighteenth Edition). Structured around a Cable Sizing Template (CST) – which acts jointly as both a design check-list and a record sheet – users are guided towards an optimal design solution. The four necessary parameters of: protection against over-current, protection against short-circuit, protection against electric shock and voltage drop can each be independently assessed either for a complete design process or for spot comparison against software output.

In addition, although in many cases cable sizing calculations will be undertaken by the use of proprietary software, completion of the module will give the users of such packages a greater understanding of the calculations the software is undertaking, thereby enabling them to utilise such software more effectively. The principle being that in order to effectively understand and use any software package, you first have to be able to undertake the calculations by hand.

To pay via invoice, or if you would like purchase a course on behalf of another delegate please complete our booking form.

* If you are having any difficulties please either email us at [email protected].
